Product model	Alternative model	Product description	View details
HLT-100030SN400M6B0	100030SN400M6B0	Low ESR/ESL capacitor, D=2.4~2.6 mm, d=0.8~0.9mm, capacitance 40pF ±20%, working voltage 25V, dielectric withstand voltage 63V, dielectric material NP0, operating temperature -55°C to +125°C.	View details
HLT-100030SX223K6B0	100030SX223K6B0	Low ESR/ESL capacitor, D=2.4~2.6 mm, d=0.8~0.9 mm, capacitance 22000 pF ±10%, working voltage 25 V, dielectric withstand voltage 63 V, dielectric material X7R, operating temperature -55°C to +125°C.	View details
HLT-100030SN300M6B0	100030SN300M6B0	Low ESR/ESL capacitor, D=2.4~2.6 mm, d=0.8~0.9mm, capacitance 30pF ±20%, working voltage 25V, dielectric withstand voltage 63V, dielectric material NP0, operating temperature -55°C to +125°C.	View details
HLT-100030SX222M6B0	100030SX222M6B0	Low ESR/ESL capacitor, D=2.4~2.6 mm, d=0.8~0.9 mm, capacitance 2200 pF ±20%, working voltage 25 V, dielectric withstand voltage 63 V, dielectric material X7R, operating temperature -55°C to +125°C.	View details
HLT-100030SN281M6B0	100030SN281M6B0	Low ESR/ESL capacitor, D=2.4~2.6 mm, d=0.8~0.9mm, capacitance 280pF ±20%, working voltage 25V, dielectric withstand voltage 63V, dielectric material NP0, operating temperature -55°C to +125°C.	View details
HLT-100030SX203M6B0	100030SX203M6B0	Low ESR/ESL capacitor, D=2.4~2.6 mm, d=0.8~0.9 mm, capacitance 20000 pF ±20%, working voltage 25 V, dielectric withstand voltage 63 V, dielectric material X7R, operating temperature -55°C to +125°C.	View details
HLT-100030SX183M6B0	100030SX183M6B0	Low ESR/ESL capacitor, D=2.4~2.6 mm, d=0.8~0.9 mm, capacitance 18000 pF ±20%, working voltage 25 V, dielectric withstand voltage 63 V, dielectric material X7R, operating temperature -55°C to +125°C.	View details
HLT-100030SN221M6B0	100030SN221M6B0	Low ESR/ESL capacitor, D=2.4~2.6 mm, d=0.8~0.9mm, capacitance 220pF ±20%, working voltage 25V, dielectric withstand voltage 63V, dielectric material NP0, operating temperature -55°C to +125°C.	View details
HLT-100030SN151M6B0	100030SN151M6B0	Low ESR/ESL capacitor, D=2.4~2.6 mm, d=0.8~0.9mm, capacitance 150pF ±20%, working voltage 25V, dielectric withstand voltage 63V, dielectric material NP0, operating temperature -55°C to +125°C.	View details
HLT-100030SX153M6B0	100030SX153M6B0	Low ESR/ESL capacitor, D=2.4~2.6 mm, d=0.8~0.9 mm, capacitance 15000 pF ±20%, working voltage 25 V, dielectric withstand voltage 63 V, dielectric material X7R, operating temperature -55°C to +125°C.	View details
HLT-100030SN150M6B0	100030SN150M6B0	Low ESR/ESL capacitor, D=2.4~2.6 mm, d=0.8~0.9mm, capacitance 15pF ±20%, working voltage 25V, dielectric withstand voltage 63V, dielectric material NP0, operating temperature -55°C to +125°C.	View details
HLT-100030SX153K6B0	100030SX153K6B0	Low ESR/ESL capacitor, D=2.4~2.6 mm, d=0.8~0.9 mm, capacitance 15000 pF ±10%, working voltage 25 V, dielectric withstand voltage 63 V, dielectric material X7R, operating temperature -55°C to +125°C.	View details
HLT-100030SN110M6B0	100030SN110M6B0	Low ESR/ESL capacitor, D=2.4~2.6 mm, d=0.8~0.9mm, capacitance 11pF ±20%, working voltage 25V, dielectric withstand voltage 63V, dielectric material NP0, operating temperature -55°C to +125°C.	View details
HLT-100030SX152M6B0	100030SX152M6B0	Low ESR/ESL capacitor, D=2.4~2.6 mm, d=0.8~0.9 mm, capacitance 1500 pF ±20%, working voltage 25 V, dielectric withstand voltage 63 V, dielectric material X7R, operating temperature -55°C to +125°C.	View details
HLT-100030SN101M6B0	100030SN101M6B0	Low ESR/ESL capacitor, D=2.4~2.6 mm, d=0.8~0.9mm, capacitance 100pF ±20%, working voltage 25V, dielectric withstand voltage 63V, dielectric material NP0, operating temperature -55°C to +125°C.	View details
HLT-100030SX143M6B0	100030SX143M6B0	Low ESR/ESL capacitor, D=2.4~2.6 mm, d=0.8~0.9 mm, capacitance 14000 pF ±20%, working voltage 25 V, dielectric withstand voltage 63 V, dielectric material X7R, operating temperature -55°C to +125°C.	View details
HLT-100030SN100M6B0	100030SN100M6B0	Low ESR/ESL capacitor, D=2.4~2.6 mm, d=0.8~0.9mm, capacitance 10pF ±20%, working voltage 25V, dielectric withstand voltage 63V, dielectric material NP0, operating temperature -55°C to +125°C.	View details
HLT-100030SX124M6B0	100030SX124M6B0	Low ESR/ESL capacitor, D=2.4~2.6 mm, d=0.8~0.9 mm, capacitance 120000 pF ±20%, working voltage 25 V, dielectric withstand voltage 63 V, dielectric material X7R, operating temperature -55°C to +125°C.	View details
HLT-100030SN7R5M6B0	100030SN7R5M6B0	Low ESR/ESL capacitor, D=2.4~2.6 mm, d=0.8~0.9mm, capacitance 7.5pF ±20%, working voltage 25V, dielectric withstand voltage 63V, dielectric material NP0, operating temperature -55°C to +125°C.	View details
HLT-100030SX123M6B0	100030SX123M6B0	Low ESR/ESL capacitor, D=2.4~2.6 mm, d=0.8~0.9 mm, capacitance 12000 pF ±20%, working voltage 25 V, dielectric withstand voltage 63 V, dielectric material X7R, operating temperature -55°C to +125°C.	View details
