| Product model |
Alternative model |
Product images |
Product description |
View details |
| HN-RF3016-0.5(8-2) |
RF glass insulator |
|
Outer diameter of conductor, height, as well as diameter, shape and length of the pin can be customized according to customer requirements |
View details |
| HN-DC2015-0.8(6.5-2)M |
Single-core glass insulator (Glass bead) |
|
Outer diameter of conductor, height, as well as diameter, shape and length of the pin can be customized according to customer requirements. |
View details |
| H3-B50-4-2-800M |
Frequency range: 2-800MHz, impedance 50 Ω, impedance ratio 1:4 |
 |
Frequency range: 2-800MHz, impedance 50 Ω, impedance ratio 1:4 |
View details |
| HN-RF3016-0.5(6.2-3.7) |
RF glass insulator |
|
Outer diameter of conductor, height, as well as diameter, shape and length of the pin can be customized according to customer requirements |
View details |
| HN-RF3016-0.5(7.8-2)R |
RF glass insulator |
|
Outer diameter of conductor, height, as well as diameter, shape and length of the pin can be customized according to customer requirements |
View details |
| HN-DC2014-0.7(11.4-1.2)-T0.9 |
Single-core glass insulator (Glass bead) |
|
Outer diameter of conductor, height, as well as diameter, shape and length of the pin can be customized according to customer requirements. |
View details |
| H3-B50-1-0.25-750M |
Frequency range: 0.25-750MHz, impedance 50 Ω, impedance ratio 1:1 |
 |
Frequency range: 0.25-750MHz, impedance 50 Ω, impedance ratio 1:1 |
View details |
| HLT-100030SX223K6B0 |
100030SX223K6B0 |
|
Low ESR/ESL capacitor, D=2.4~2.6 mm, d=0.8~0.9 mm, capacitance 22000 pF ±10%, working voltage 25 V, dielectric withstand voltage 63 V, dielectric material X7R, operating temperature -55°C to +125°C. |
View details |
| HN-DC2014-0.7(10.4-1)-T0.9 |
Single-core glass insulator (Glass bead) |
|
Outer diameter of conductor, height, as well as diameter, shape and length of the pin can be customized according to customer requirements. |
View details |
| H3-WBC1-1TLC |
WBC1-1TLC |
 |
Frequency range: 0.4-500MHz, impedance 50 Ω, impedance ratio 1:1 |
View details |
| HN-RF2816-0.45(12-3) |
RF Glass Insulator (Glass Bead) |
 |
Impedance: 50Ω
Frequency Range: 0.05~26.5GHz
VSWR: ≤1.2
Insertion Loss: ≤0.2dB
Insulation Resistance: ≥5000MΩ@500V
Dielectric Withstanding Voltage: ≥300V
Seal Leakage Rate: ≤1.013x10-3Pa·cm3/S
Service Life: ≥500 times
Temperature Range: -65°C~+155°C
Customizable according to customer requirements |
View details |
| HLT-100030SX222M6B0 |
100030SX222M6B0 |
|
Low ESR/ESL capacitor, D=2.4~2.6 mm, d=0.8~0.9 mm, capacitance 2200 pF ±20%, working voltage 25 V, dielectric withstand voltage 63 V, dielectric material X7R, operating temperature -55°C to +125°C. |
View details |
| HN-RF2816-0.45(8-4.6)M |
RF glass insulator |
|
Outer diameter of conductor, height, as well as diameter, shape and length of the pin can be customized according to customer requirements |
View details |
| HN-DC2010-0.5(6-2) |
Single-core glass insulator (Glass bead) |
|
Outer diameter of conductor, height, as well as diameter, shape and length of the pin can be customized according to customer requirements. |
View details |
| H3-TRS2-1T-75+ |
TRS2-1T-75+ |
 |
Frequency range: 5-1200MHz, impedance 75 Ω, impedance ratio 1:2, operating temperature: -40 ℃~+85 ℃, Balun transformer |
View details |
| HLT-100030SX203M6B0 |
100030SX203M6B0 |
|
Low ESR/ESL capacitor, D=2.4~2.6 mm, d=0.8~0.9 mm, capacitance 20000 pF ±20%, working voltage 25 V, dielectric withstand voltage 63 V, dielectric material X7R, operating temperature -55°C to +125°C. |
View details |
| HLT-100030SX183M6B0 |
100030SX183M6B0 |
|
Low ESR/ESL capacitor, D=2.4~2.6 mm, d=0.8~0.9 mm, capacitance 18000 pF ±20%, working voltage 25 V, dielectric withstand voltage 63 V, dielectric material X7R, operating temperature -55°C to +125°C. |
View details |
| HN-RF2816-0.45(8-4.6) |
RF Glass Insulator (Glass Bead) |
 |
Impedance: 50Ω
Frequency Range: 0.05~26.5GHz
VSWR: ≤1.2
Insertion Loss: ≤0.2dB
Insulation Resistance: ≥5000MΩ@500V
Dielectric Withstanding Voltage: ≥300V
Seal Leakage Rate: ≤1.013x10-3Pa·cm3/S
Service Life: ≥500 times
Temperature Range: -65°C~+155°C
Customizable according to customer requirements |
View details |
| HN-DC1616-0.45(16-4) |
Single-core glass insulator (Glass bead) |
 |
Outer diameter of conductor, height, as well as diameter, shape and length of the pin can be customized according to customer requirements. |
View details |
| H3-TRS1-182-75+ |
TRS1-182-75+ |
 |
Frequency range: 10-1800MHz, impedance 75 Ω, impedance ratio 1:1, operating temperature: -40 ℃~+125 ℃, Balun transformer |
View details |
