| Product model |
Alternative model |
Product images |
Product description |
View details |
| HN-DC2016-0.5(9-2.5) |
Single-core glass insulator (Glass bead) |
|
Outer diameter of conductor, height, as well as diameter, shape and length of the pin can be customized according to customer requirements. |
View details |
| HN-RF3016-0.5(12-5)M |
RF glass insulator |
|
Outer diameter of conductor, height, as well as diameter, shape and length of the pin can be customized according to customer requirements |
View details |
| HN-DC2016-0.5(6-2) |
Single-core glass insulator (Glass bead) |
 |
Outer diameter of conductor, height, as well as diameter, shape and length of the pin can be customized according to customer requirements. |
View details |
| HN-RF3016-0.5(12-5) |
RF glass insulator |
|
Outer diameter of conductor, height, as well as diameter, shape and length of the pin can be customized according to customer requirements |
View details |
| HN-DC2016-0.5(6.5-2)M |
Single-core glass insulator (Glass bead) |
|
Outer diameter of conductor, height, as well as diameter, shape and length of the pin can be customized according to customer requirements. |
View details |
| HN-RF3016-0.5(12-2) |
RF glass insulator |
|
Outer diameter of conductor, height, as well as diameter, shape and length of the pin can be customized according to customer requirements |
View details |
| HN-DC2016-0.5(6.5-2) |
Single-core glass insulator (Glass bead) |
 |
Outer diameter of conductor, height, as well as diameter, shape and length of the pin can be customized according to customer requirements. |
View details |
| HN-RF3016-0.5(9-3) |
RF glass insulator |
|
Outer diameter of conductor, height, as well as diameter, shape and length of the pin can be customized according to customer requirements |
View details |
| HN-DC2015-0.8(11-0.9)M |
Single-core glass insulator (Glass bead) |
|
Outer diameter of conductor, height, as well as diameter, shape and length of the pin can be customized according to customer requirements. |
View details |
| HN-RF3016-0.5(8-2) |
RF glass insulator |
|
Outer diameter of conductor, height, as well as diameter, shape and length of the pin can be customized according to customer requirements |
View details |
| HN-DC2015-0.8(6.5-2)M |
Single-core glass insulator (Glass bead) |
|
Outer diameter of conductor, height, as well as diameter, shape and length of the pin can be customized according to customer requirements. |
View details |
| HN-RF3016-0.5(6.2-3.7) |
RF glass insulator |
|
Outer diameter of conductor, height, as well as diameter, shape and length of the pin can be customized according to customer requirements |
View details |
| HN-RF3016-0.5(7.8-2)R |
RF glass insulator |
|
Outer diameter of conductor, height, as well as diameter, shape and length of the pin can be customized according to customer requirements |
View details |
| HN-DC2014-0.7(11.4-1.2)-T0.9 |
Single-core glass insulator (Glass bead) |
|
Outer diameter of conductor, height, as well as diameter, shape and length of the pin can be customized according to customer requirements. |
View details |
| HN-DC2014-0.7(10.4-1)-T0.9 |
Single-core glass insulator (Glass bead) |
|
Outer diameter of conductor, height, as well as diameter, shape and length of the pin can be customized according to customer requirements. |
View details |
| HN-RF2816-0.45(12-3) |
RF Glass Insulator (Glass Bead) |
 |
Impedance: 50Ω
Frequency Range: 0.05~26.5GHz
VSWR: ≤1.2
Insertion Loss: ≤0.2dB
Insulation Resistance: ≥5000MΩ@500V
Dielectric Withstanding Voltage: ≥300V
Seal Leakage Rate: ≤1.013x10-3Pa·cm3/S
Service Life: ≥500 times
Temperature Range: -65°C~+155°C
Customizable according to customer requirements |
View details |
| HN-RF2816-0.45(8-4.6)M |
RF glass insulator |
|
Outer diameter of conductor, height, as well as diameter, shape and length of the pin can be customized according to customer requirements |
View details |
| HN-DC2010-0.5(6-2) |
Single-core glass insulator (Glass bead) |
|
Outer diameter of conductor, height, as well as diameter, shape and length of the pin can be customized according to customer requirements. |
View details |
| HN-RF2816-0.45(8-4.6) |
RF Glass Insulator (Glass Bead) |
 |
Impedance: 50Ω
Frequency Range: 0.05~26.5GHz
VSWR: ≤1.2
Insertion Loss: ≤0.2dB
Insulation Resistance: ≥5000MΩ@500V
Dielectric Withstanding Voltage: ≥300V
Seal Leakage Rate: ≤1.013x10-3Pa·cm3/S
Service Life: ≥500 times
Temperature Range: -65°C~+155°C
Customizable according to customer requirements |
View details |
| HN-DC1616-0.45(16-4) |
Single-core glass insulator (Glass bead) |
 |
Outer diameter of conductor, height, as well as diameter, shape and length of the pin can be customized according to customer requirements. |
View details |
