| Product model |
Alternative model |
Product images |
Product description |
View details |
| HN-RF2018-0.3(6-1.2)R |
RF glass insulator |
|
Outer diameter of conductor, height, as well as diameter, shape and length of the pin can be customized according to customer requirements |
View details |
| HN-DC1410-0.5(5-2) |
Single-core glass insulator (Glass bead) |
|
Outer diameter of conductor, height, as well as diameter, shape and length of the pin can be customized according to customer requirements. |
View details |
| HN-DC1313-0.45(6-1)M |
Single-core glass insulator (Glass bead) |
|
Outer diameter of conductor, height, as well as diameter, shape and length of the pin can be customized according to customer requirements. |
View details |
| HN-RF2016-0.3(13.6-6) |
RF Glass Insulator (Glass Bead) |
 |
Impedance: 50Ω
Frequency Range: 0.05~46.5GHz
VSWR: ≤1.2
Insertion Loss: ≤0.2dB
Insulation Resistance: ≥5000MΩ@500V
Dielectric Withstanding Voltage: ≥300V
Seal Leakage Rate: ≤1.013x10-3Pa·cm3/S
Service Life: ≥500 times
Temperature Range: -65°C~+155°C
Customizable according to customer requirements |
View details |
| HN-DC1216-0.45(16-2.8) |
Single-core glass insulator (Glass bead) |
 |
Outer diameter of conductor, height, as well as diameter, shape and length of the pin can be customized according to customer requirements. |
View details |
| HN-RF2016-0.3(12-2.4) |
RF Glass Insulator (Glass Bead) |
 |
Impedance: 50Ω
Frequency Range: 0.05~46.5GHz
VSWR: ≤1.2
Insertion Loss: ≤0.2dB
Insulation Resistance: ≥5000MΩ@500V
Dielectric Withstanding Voltage: ≥300V
Seal Leakage Rate: ≤1.013x10-3Pa·cm3/S
Service Life: ≥500 times
Temperature Range: -65°C~+155°C
Customizable according to customer requirements |
View details |
| HN-RF2016-0.3(8-4.6)R |
RF glass insulator |
|
Outer diameter of conductor, height, as well as diameter, shape and length of the pin can be customized according to customer requirements |
View details |
| HN-DC1216-0.45(14-1.2)M-3 |
Single-core glass insulator (Glass bead) |
|
Outer diameter of conductor, height, as well as diameter, shape and length of the pin can be customized according to customer requirements. |
View details |
| HN-DC1216-0.45(12-4.6) |
Single-core glass insulator (Glass bead) |
|
Outer diameter of conductor, height, as well as diameter, shape and length of the pin can be customized according to customer requirements. |
View details |
| HN-RF2016-0.3(8-4.6) |
RF Glass Insulator (Glass Bead) |
 |
Impedance: 50Ω
Frequency Range: 0.05~46.5GHz
VSWR: ≤1.2
Insertion Loss: ≤0.2dB
Insulation Resistance: ≥5000MΩ@500V
Dielectric Withstanding Voltage: ≥300V
Seal Leakage Rate: ≤1.013x10-3Pa·cm3/S
Service Life: ≥500 times
Temperature Range: -65°C~+155°C
Customizable according to customer requirements |
View details |
| HN-RF2016-0.3(8-2)M |
RF glass insulator |
|
Outer diameter of conductor, height, as well as diameter, shape and length of the pin can be customized according to customer requirements |
View details |
| HN-DC1216-0.45(12-2.8)M |
Single-core glass insulator (Glass bead) |
|
Outer diameter of conductor, height, as well as diameter, shape and length of the pin can be customized according to customer requirements. |
View details |
| HN-DC1216-0.45(12-2.8) |
Single-core glass insulator (Glass bead) |
|
Outer diameter of conductor, height, as well as diameter, shape and length of the pin can be customized according to customer requirements. |
View details |
| HN-RF2016-0.3(8-1.8)R |
RF Glass Insulator (Glass Bead) |
 |
Impedance: 50Ω
Frequency Range: 0.05~46.5GHz
VSWR: ≤1.2
Insertion Loss: ≤0.2dB
Insulation Resistance: ≥5000MΩ@500V
Dielectric Withstanding Voltage: ≥300V
Seal Leakage Rate: ≤1.013x10-3Pa·cm3/S
Service Life: ≥500 times
Temperature Range: -65°C~+155°C
Customizable according to customer requirements |
View details |
| HN-RF2014-0.3(4.4-1.5)R |
RF glass insulator |
|
Outer diameter of conductor, height, as well as diameter, shape and length of the pin can be customized according to customer requirements |
View details |
| HN-DC1216-0.45(12-2.4)M |
Single-core glass insulator (Glass bead) |
|
Outer diameter of conductor, height, as well as diameter, shape and length of the pin can be customized according to customer requirements. |
View details |
| HN-RF2014-0.3(4.4-1.5) |
RF glass insulator |
|
Outer diameter of conductor, height, as well as diameter, shape and length of the pin can be customized according to customer requirements |
View details |
| HN-DC1216-0.45(12-1.2)MDR |
Single-core glass insulator (Glass bead) |
|
Outer diameter of conductor, height, as well as diameter, shape and length of the pin can be customized according to customer requirements. |
View details |
| HN-DC1216-0.45(8-2.8)M |
Single-core glass insulator (Glass bead) |
|
Outer diameter of conductor, height, as well as diameter, shape and length of the pin can be customized according to customer requirements. |
View details |
| HN-RF2014-0.3(4.4-1)R |
RF Glass Insulator (Glass Bead) |
 |
Characteristic Impedance: 50Ω
Frequency Range: 0.05~46.5GHz
VSWR: ≤1.2
Insertion Loss: ≤0.2dB
Insulation Resistance: ≥5000MΩ@500V
Dielectric Withstanding Voltage: ≥300V
Seal Leakage Rate: ≤1.013x10-3Pa·cm3/S
Service Life: ≥500 times
Temperature Range: -65°C~+155°C
Customizable according to customer requirements |
View details |
